2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Pennyflake — image 1

2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5

Pennyflake / Small
R 146,151.60 R 173,990.00
Skip to product information
2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Pennyflake — image 1
  • 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Pennyflake — image 1
  • 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Deep Smoke — image 2
  • 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Deep Smoke — image 3
  • 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Deep Smoke — image 4
  • 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Deep Smoke — image 5
  • 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Deep Smoke — image 6
  • 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Deep Smoke — image 7
2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5

2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5

R 146,151.60 R 173,990.00
Colour
Size
In stock

The 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 is built for steep, technical riding with a focus on descending. Pedal assistance adds support to your effort; review the motor and battery specification for this build. Compare the listed frame, components and size options to choose your setup.

Specifications — Pennyflake

Model 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Pennyflake
Frame OCLV Mountain Carbon main frame, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH Boost148, 12 mm thru axle, 160 mm travel
Fork Fox Performance Elite Float 38, Float EVOL air spring, GRIP X damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt-X axle, 160 mm travel
Shock Fox Performance Elite Float X, 2-position damper, 205mm x 65mm
Max compatible fork travel 180 mm
Wheel front Size: S | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 27.5" | Size: M, L, XL | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"
Wheel rear Bontrager Line Comp 30, High Strength 6000 Series Aluminium rim, Tubeless-Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12 mm thru axle, 27.5"
Skewer rear Bontrager Switch thru-axle, removable lever
Tyre Size: S, M, L, XL | Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 27.5x2.50" | Size: M, L, XL | Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 29x2.50"
Tyre part Bontrager TLR sealant, 180 ml/6 oz
Rim strip Bontrager TLR
Max tyre size Frame: 27.5x2.60", Fork: See manufacturer
Battery Bosch PowerTube 800 Wh, smart system
Charger Bosch standard 4A, 110 V, smart system
Controller Bosch System Controller BRC3100, smart system
Motor Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Shifter SRAM AXS POD
Rear derailleur SRAM GX Eagle AXS, T-Type
Crank SRAM GX, 160 mm length
Cassette SRAM Eagle XS-1275, T-Type,10-52, 12-speed
Chain SRAM GX Eagle, T-Type, 12-speed
Pedal VP-536 nylon platform
Max. chainring size 1x: 36T
Saddle Verse Short Comp, steel rails, 145 mm width
Seatpost Size: S | Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length | Size: M, L, XL | Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length | Size: L, XL | Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Handlebar Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width
Grips Bontrager XR Trail Elite, nylon lock-on
Stem Bontrager Line Pro, 35 mm, Blendr-compatible, 0-degree, 45 mm length
Head set Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible
Brake SRAM CODE Bronze 4-piston hydraulic disc
Brake rotor Size: S, M, L, XL | SRAM 6-bolt, 200 mm | Size: S, M, L, XL | SRAM HS2, 6-bolt, 220mm
Rotor size Max brake rotor sizes – Frame: 220 mm, Fork: see fork manufacturer
Mudguard Trek 27.5" custom fender
Weight M - 24.18 kg/53.31 lb (with TLR sealant, no tubes)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).

Specifications — Deep Smoke

Model 2027 Trek Rail+ 9.8 GX AXS T-Type Gen 5 - Deep Smoke
Frame OCLV Mountain Carbon main frame, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH Boost148, 12 mm thru axle, 160 mm travel
Fork Fox Performance Elite Float 38, Float EVOL air spring, GRIP X damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt-X axle, 160 mm travel
Shock Fox Performance Elite Float X, 2-position damper, 205mm x 65mm
Max compatible fork travel 180 mm
Wheel front Size: S | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 27.5" | Size: M, L, XL | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"
Wheel rear Bontrager Line Comp 30, High Strength 6000 Series Aluminium rim, Tubeless-Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12 mm thru axle, 27.5"
Skewer rear Bontrager Switch thru-axle, removable lever
Tyre Size: S, M, L, XL | Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 27.5x2.50" | Size: M, L, XL | Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 29x2.50"
Tyre part Bontrager TLR sealant, 180 ml/6 oz
Rim strip Bontrager TLR
Max tyre size Frame: 27.5x2.60", Fork: See manufacturer
Battery Bosch PowerTube 800 Wh, smart system
Charger Bosch standard 4A, 110 V, smart system
Controller Bosch System Controller BRC3100, smart system
Motor Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Shifter SRAM AXS POD
Rear derailleur SRAM GX Eagle AXS, T-Type
Crank SRAM GX, 160 mm length
Cassette SRAM Eagle XS-1275, T-Type,10-52, 12-speed
Chain SRAM GX Eagle, T-Type, 12-speed
Pedal VP-536 nylon platform
Max. chainring size 1x: 36T
Saddle Verse Short Comp, steel rails, 145 mm width
Seatpost Size: S | Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length | Size: M, L, XL | Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length | Size: L, XL | Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Handlebar Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width
Grips Bontrager XR Trail Elite, nylon lock-on
Stem Bontrager Line Pro, 35 mm, Blendr-compatible, 0-degree, 45 mm length
Head set Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible
Brake SRAM CODE Bronze 4-piston hydraulic disc
Brake rotor Size: S, M, L, XL | SRAM 6-bolt, 200 mm | Size: S, M, L, XL | SRAM HS2, 6-bolt, 220mm
Rotor size Max brake rotor sizes – Frame: 220 mm, Fork: see fork manufacturer
Mudguard Trek 27.5" custom fender
Weight M - 24.18 kg/53.31 lb (with TLR sealant, no tubes)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).

The Deep Smoke build does not include a Kiox 400 display.
